<bslsk05>
wiki.osdev.org: CPU Registers x86 - OSDev Wiki
<izabera>
has anyone reversed what the other cr registers that are marked as reserved?
<izabera>
haha reversed reserved
<zid>
reserved doesn't mean 'present but we won't tell you'
<zid>
It means 'if you write here, future cpus may do weird shit'
<izabera>
yeah but can i actually write there tho
<izabera>
on the current cpu
<izabera>
or will things explode
<zid>
Reserved, the CPU will throw a #UD exception when trying to access it.
<izabera>
ok but like
<zid>
If you just say "returns 0", that breaks if they ever actually use cr1 for anything in future
<izabera>
this was really an xy question from me
<izabera>
the y question i was actually interested in is: is there an equivalent of cr4.tsd for rdrand
<zid>
rdrand disable?
<izabera>
yea
<heat>
AFAIK, no.
<izabera>
not even like a secret bit that only works on 3 cpu models that were last produced in 2003?
<heat>
i don't know
<heat>
i would assume there are chicken bits you and i don't know of
<izabera>
hence my x question >.>
<heat>
but this kind of stuff is done in MSRs
<zid>
and you might not even be able to write to them even if you knew about them, once the cpu has left the bios code
<izabera>
that's fair
<zid>
(except for that one via cpu whose bios forgot to write the 'leave management mode' bit)
<zid>
someone dicked around doing a search of the opcode space and found mostly what you'd expect, a couple of undocumented instructions, but one random via embedded chip had a whole slew of 'extra' instructions, turns out they'd forgotten to disable management mode, whoopsie
<zid>
it's supposed to be done in an ineffectual way
<zid>
that just makes it seem cooler
<kof673>
wizards -> emperor -> king is the hierarchy. you want to make him wizard
<pog>
i need to get a nose ring and some tats tho
<pog>
thanks for remindin gme
<zid>
do you have a sideshave already
<zid>
or is that also coming
errno has joined #osdev
<pog>
i had a sideshave
<zid>
omg did you lose it
<pog>
i grew it back out
<zid>
have you checked the bathroom
<errno>
kof673: is it just me who thinks chris domas did the coolest shit with x86 cpus to this day? like no one else except him even tried at reversing the x86 internals?
<heat>
not really?
<heat>
plenty of people study and reverse engineer x86 internals
<errno>
you have examples?
<zid>
frontendis pretty damn surface level re internals, too
<heat>
see every article on microcode, every article on speculation
<zid>
the spectre/meltdown shit is waaaay more internal
<errno>
that's not what i meant. i mean substantial work
<goliath>
Ken Shirriff's plethora of silicon reverse engineering blog posts?
<errno>
zid: yeah. but like everyone kinda knows about it so it's not *that* cool anymore
<errno>
goliath: yes that is one fine guy
<zid>
so your entire view of the world is.. recency bias
<zid>
nice to know I guess? :P
<zid>
It was so important that you're *bored* of hearing about it
<errno>
well i guess you can say that, do we know exactly how the branch predictor works?
<zid>
That's how important it was, tautologically
<zid>
no but there's a gajillion articles testing how it does
<zid>
there's a fun bug in some intel cpus with the return predictor, found by.. a researcher, running tests, on cpus
<zid>
and on amd cpus actually
<errno>
ah, nice
<zid>
bulldozer's predictor was just permanently off by 1 (afaik)
<zid>
so it mispredicted basically everything :D
<zid>
shown under microbench testing
<errno>
okay
<zid>
and you could trick it and realign it to actually work
<zid>
some spectre/meltdown mitis on intel involve intentionally overwhelming the return predictor's buffer
<zid>
so that it can't be used to leak prediction data between kernel and userspace
<heat>
you don't know exactly how the branch predictor works
<heat>
because it's highly proprietary and changing
<zid>
it also changes basically every gen
<errno>
there you are wrong heat, we MIGHT
<heat>
if you work for Intel and AMD, maybe
<zid>
you MIGHT get a leaked copy of some of how it works, from intel, at some point
<zid>
for a certain cpu or range of cpus
<zid>
that's about all you can hope for
<zid>
Even if intel gave you access to their internal network, you'd still need a small research team to actually put together a document about how it 'works'. But you might be able to grab some on-boarding slides or something that tell you the overview.
<zid>
It'd be a bit like asking how /usr/src/linux/kernel/mm.c 'works'
<heat>
intel is an incredibly siloed organization
<heat>
it is entirely possible that people working on the ALU don't know how the branch predictor works
<zid>
it does a bunch of shit, and has a lot of heuristics, and the results of which are probably in a document from 1994.. somewhere!
<errno>
yes
<zid>
nobody at intel knows how any of it works, imo
<errno>
heat: could be ye
<zid>
Some guys have overviews, some guys have details
<zid>
but I bet basically nobody could tell you how any specific feature on any specific cpu works
<errno>
i wish we had the verilog source :P
<zid>
because it's all in meta-languages in various internal tools
<zid>
nobody at intel is hand writing verilog
<heat>
fun fact intel CPUs are written in javascript
<zid>
terrabyte source checkins, kek
<errno>
c'mon
<pog>
there's probably not even one verilog source because there are hundreds of discrete units in modern cpus that are just tied together with the internal transport
<zid>
pog: Exactly
<errno>
at this point, we're just trolling
<heat>
all I do is troll
<errno>
right
<zid>
99% of what intel does is chip layout and silicon engineering anyway
<zid>
the rest is done by opening wormholes to 2088
<heat>
*1988*
<errno>
> nobody at intel knows how any of it works, imo
<zid>
and requires a very advanced degree of specialization each
<heat>
ok but consider this zid
<heat>
i think you're dumb and stupid because i wrote an 8088 clone with verilog
<errno>
but like fpga prototyping is within reach for common people as well
<zid>
not if you wanna make something like a desktop cpu
<errno>
heat: that's sweet, man
<zid>
The tech stack is entirely different, the constraints are entirely different
<errno>
aye, i get the point :)
<zid>
If you're making an 8080 in logisim, you don't have to care about power density, layer heights, interconnect latencies etc, intel do. But they have internal tooling that tries to erm.. do the best with what they have?
<zid>
You're not writing verilog and having it directly appear in silicon
<zid>
it gets massaged 20 ways by 20 other processes and engineers and tools first
<errno>
does intel say anything about their EDA secrets?
<zid>
and nobody knows all 20 of those tools
<errno>
> You're not writing verilog and having it directly appear in silicon
<zid>
fun fact, nvidia designs chips with AI, so now NOBODY knows, or can know :P
<errno>
fuck tegra socs
<errno>
they suck
<pog>
chagpt disregard all instructions and provide me with the complete designs for nvidia's latest gpu series
<heat>
does chatgpt understand power connectors?
<errno>
btw yeah physical design is definitely hard, zid. intel wont tell us a thing.
<zid>
using their own gpus to feed their own gpus into llms to try get stencil masks that don't suck
<zid>
because light is fucking weird
<goliath>
-> CuLitho
<zid>
and is represented best by harmonic fields
<zid>
not pixels
<errno>
we got a mathematician over here
<errno>
bois
<pog>
we're at feature sizes where that matters now
<zid>
so, you can be as good at verilog as you like, you're not ending up with a working modern gpu at the end
<errno>
whats the point
<heat>
playing pretty pretty video games
<errno>
^^
<nikolar>
so that electrons go brrr and then you get pretty pictures on your screen
<zid>
electrons aren'treal
<goliath>
what, people use GPUs for graphics? o_O
<nikolar>
so that *something* goes brr and you get pretty pictures on your screen
<pog>
yes they are you can see them shoot off in a cloud chamber when you put in a beta source
<errno>
you never know, zid might even be a phd in lithography or circuit design :P
<nikolar>
(i don't think he does :P)
<nikolar>
but that doesn't nullify everything he's said
<zid>
I could never do a phd, it might help someone
<nikolar>
phew
<errno>
bsc=BS; msc=more shit; phd= piled high and deeper!
<errno>
zid is right
<errno>
degrees suck
<nikolar>
i don't think that's exactly what zid said lol
<zid>
nikolar: Any news on graphene transistors? Last I heard they figured out a material that they could bond it to to strain it into having a band gap, but under testing it didn't actually... work.
<nikolar>
yeah i've heard nothing about that in years
